Wireless charging PSE certification processing——ZRLK

Wireless charging is a device that uses the principle of electromagnetic induction to charge. By placing a coil at the transmitting and receiving ends, the transmitting coil sends an electromagnetic signal to the outside under the action of electric power, and the receiving coil receives the electromagnetic signal and converts the electromagnetic signal into Electricity, so as to achieve the purpose of wireless charging, but in general, whether this kind of wireless products are directly exported or put on the Japanese Amazon platform, they need to apply for the Japanese PSE certification.

What is PSE certification?

PSE certification is a Japanese compulsory safety certification, which is used to prove that electrical and electronic products have passed the safety standard test of the Japanese Electrical and Material Safety Law (DENAN Law) or the international IEC standard. Japan’s DENTORL Law (Electrical Device and Material Control Law) stipulates that 498 products must pass safety certification to enter the Japanese market. Among them, 165 types of A products should obtain the diamond-shaped PSE mark, and 333 types of B products should obtain the round PSE mark.

Information to be prepared for PSE certification

1. Application submission information:

Business license, application form.

2. Test preparation information:

(1) CB report (including Japanese difference test);

(2) Layout drawing;

(3) PCB design drawings related to safety regulations;

(4) Specifications of transformer and coil parts;

(5) List of key components and their certificates;

(6) Japanese manual or assembly manual;

(7) Japanese nameplates and warning signs (including PSE logo and notified supplier name);

(8) Structural data table;

(9) List of production and calibration certificates used in factory production.

3. Provide samples for testing:

There are at least two main test models, one for each derived model.

PSE certification application process

1. The customer prepares samples, application forms and materials and submits them to a domestic third-party laboratory;

2. The domestic third-party laboratory conducts the test. If the PSE is round, the domestic third-party laboratory will issue a declaration letter;

3. For PSE rhombus, factory inspection is needed; for the time being, domestic agents are all agents-the operation is more troublesome;

4. After passing the PSE diamond test and factory inspection, the issuing agency will issue a PSE diamond certificate;

5. PSE round: After passing the test by the domestic third-party laboratory, a draft report will be issued, and a formal report will be issued after confirmation.

For wireless charging PSE certification, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services with favorable prices and courteous service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
